MIDI 2 X LOOP-er

Product code:

MIDI 2 X LOOP allows to add two additional effects loops to the guitar system.  M2L is a effects loops switcher controlled by MIDI interface or manually, by using the buttons on the casing of the device. Controlling takes place by Program Change and Control Change commands. Using the MIDI commands it is also possible to mute the signal (e.g. for silent tuning). M2L should be controlled by programmable MIDI controller (which enables to program and to send any command of PROG CHANGE or CTRL CHANGE for a given tone and preset). It is recommended to use M2L switcher as an extension of functionality for the G LAB guitar system controllers GSC. Due to its passive signal path it is also possible to use the M2L as an A/B/Y switcher.

Examples of the M2L use:



Scheme of M2L connection to the amp effect loop

Scheme of GSC extension with two effect loops

Switcher (TRUE BYPASS) for two stereo effects

two bypassed (by electro mechanic relay) loops to connect the pedal effects or serially connected sets of effects
power supply and loop switching indicators
two buttons for manual on/off switching of loops
use of muting system based on opto elements
MIDI THRU connector to connect other MIDI devices
GROUND/LIFT switch
stabilized power supply unit (9V DC, max. power consumption 60 mA)
powder-coated casing made of the sheet steel
dimensions (depth x width x height):
205 x 70 x 38 mm
weight:
0,45 kg
